Sanitary Stainless Steel Sampling Valve

Sampling valve is mainly applied to extract sample from tank or pipeline. It also can be assembled at the bottom of the tank or pipeline to drain away the remains.
Model:
Contact Now
Sanitary Stainless Steel Sampling Valve
Sanitary Stainless Steel Sampling Valve
Sanitary Stainless Steel Sampling Valve
Sanitary Stainless Steel Sampling Valve
Sanitary Stainless Steel Sampling Valve

Applications

Sampling valve is mainly applied to extract sample from tank or pipeline. It also can be assembled at the bottom of the tank or pipeline to drain away the remains.

The valve are used in a range of business areas, such as breweries, dairies, pharmaceutical and biotechnological industries, with a wide range of products such as:

  • Water
  • Milk
  • Medical solutions
  • Filtered beer
  • Perfume
  • Olive oil
  • And much more

Introdutions

This type of valves is used to obtain a sample of the medium in a pipe or equipment for the occasion of frequent chemical analysis. Sampling valve using the insulation jacket, but also should not be forced to open the valve, if the valve can not be opened, should not use the extension arm, which will cause the valve force is too large and lead to spool and stem off, Or lead to damage to the sampling parts, resulting in security risks. In the course of the use of the sampling valve, if you encounter the need to use the case of insulation jacket, it should be noted that the operation can not be completely melted in the media before the forced opening of the valve, the valve must wait until the crystal melt to open the valve, otherwise likely to cause Safety accident.

Technical parameters

Connection type: thread, clamp, weld

Max. pressure: 10bar (145psi)

Min. pressure: vacuum

Working temperature: -10℃ to +120℃

Working mode: manual, or pneumatic

Size: 1/4”, 1/2”,1”1 1/2”2”

Body material: SS316L, or SS304

Seal material: PTFE, EPDM, Silicone

Internal surface finish: Ra 0.4μm
